9999 Counts Auto Manual Ranging Digital Multimeter TRMS Multi Tester AC/DC

Regular price
Rs. 2,849.86
Regular price
Sale price
Rs. 2,849.86
Earn 1424 Reward Points. Learn More...
Terms & conditions

Your order will be delivered in 15-20 days.

Details
  • SKU: 60006526
  • Brand: SFC
  • Type: Electrical & Test Equipment
  • Availability: Out stock
Description

Description:

Auto/manual ranges, true RMS, 550V protection in resistance, capacitance and frequency ranges.

Large LCD display with backlight, max display: 9999 counts

Relative measurement, data hold, polarity identification, with auto power off function

Low voltage indication, square wave output, 9.999A high current and low current measurement

Main measurements: AC/DC voltage, AC/DC current, resistance, capacitance, diode and continuity testing, frequency and duty cycle, etc.

Specification:

Size: Approx. 130 ×65 ×32 mm/ 5.12 ×2.56 ×1.26 inch

Material: ABS

Sample rate: 3 times/ s

Frequency:0.01Hz to 9.999MHz

Capacitance :0.001nF to 9.999mF

AC volts: 0.001mV to 750V

DC volts:0.001mV to 999.9V

AC current:0.01uA to 9.999A

DC current:0.01uA to 9.999A

Resistance :0.01Ω to 9.999MΩ

Duty cycle:1% to 99%

Square Wave

Output:50Hz/100Hz/200Hz/300Hz/400Hz/500Hz/600Hz/700Hz/800Hz/900Hz/1000Hz/2000Hz/3000Hz/4000Hz/5000Hz

Capacitance: 9.999nF(±5.0%+20), 99.99nF/999.9uF/9.999uF/99.99uF/999.9uF(±2.0%+5), 9.999mF(±5.0%+5)

DC volts: 9.999mV/99.99mV/999.9mV/9.999V/99.99V/999.9V(±0.5%+3)

AC volts: 9.999mV/99.99mV/999.9mV/9.999V/99.99V/750.0V(±1.0%+3)

DC current:99.99uA/999.9uA(±0.8%+3), 999.9mA/9.999A(±1.0%+3)

AC current:99.99uA/999.9uA(±1.0%+3), 999.9mA/9.999A(±1.2%+3)

Resistance: 99.99Ω(±1.0%+3), 999.9/9.999K/99.99K/999.9K(±0.5%+3), 9.999MΩ(±1.5%+3)

Frequency: 99.99/999.9/9.999k/99.99k/999.9k/9.999M(±0.1+2)

Duty cycle: 1% to 99%(±0.1%+2)

Measurement mode: Double-integral style AC/DC transform

Over range indication: OL

Working environment: 0℃ to 40℃, humidity less than 75%

Storage environment: -20℃ to 60℃, humidity less than 80%

Battery: 2×1.5V (do not contain)

Package Includes:

1 Piece of Digital Multimeter

2 Pieces of Test Leads

1 Piece of User Manual
