3 1/2 Digits Red LED 20KΩ Resistance Panel Meter

Regular price
Rs. 1,157.52
Regular price
Sale price
Rs. 1,157.52
Earn 578 Reward Points. Learn More...
Terms & conditions

Your order will be delivered in 15-20 days.

Details
  • SKU: 14004343
  • Brand: SFC
  • Type: Business & Industrial
  • Availability: In Stock
Description

3 1/2 digits resistance meter with 0-20KΩ measuring range. Features red color LED display, this resistance meter is constructed of ABS housing with self-lock tip for panel mounting. This is a four-line system resistance meter with polarity reversed protection.

Description:

  • A 3 1/2 digit LED resistance meter
  • Designed to measure and display electronic products resistance
  • Easily readable ultra-bright red LED
  • Low power consumption
  • Over-range indication
  • Easy to install

Specifications:

  • Model: GDD5135A-20KΩ-P12V
  • Power Voltage: DC6-15.5V
  • Running Current: <50mA
  • Range: 0~19.99KΩ
  • Resolution: ±10Ω
  • Sampling Time: 2.5 / second
  • Temp Coefficient: <50PPM
  • Zero Setting: Automatic zero setting
  • Temperature Range: 0 ~ 50 deg C
  • Overrange Indication: 1 is displayed
  • Display Size: Red 0.56 inch LED
  • Outline Dimensions (L x W x H): Approx. 3.1 x 1.7 x 0.8 inch
  • Display Screen Size (L x W): Approx. 2 x 0.95 inch
  • Housing Material: ABS
  • LED Color: Red
  • Housing Color: Black

Package Includes:

  • 1 x LED resistance meter
  • 1 x Connecting cable
